PFP-6HPVGD-M-TWIN

BRIGGS & STRATTON POWERED PUMP

The Goliath model is a compact pump that delivers amazing pressure performance so as to meet the needs of several applications.

Also available in skid version

ENGINE SPECIFICATIONS

  • Vanguard, model 130000, air cooled engine
  • Single cylinder, 4-stroke gasoline engine
  • Manual recoil start
  • 0.8 gallon (3.1 l) integrated fuel tank

INCLUDED ACCESSORIES

  • Low oil level shut-off sensor

PUMP UNIT SPECIFICATIONS

  • C.E.T. dual stage centrifugal pump
  • Pump body made from aluminum
  • Aluminum impeller
  • Mechanical shaft seal
  • Self priming system
  • Two 1” (25 mm) delivery outlets and one 1 1⁄2” (38 mm) NPSH delivery outlet
  • One 1 1⁄2” (38 mm) NPSH suction inlet
  • Dimensions: Length: 24-1/2” (622 mm); Width: 16” (406 mm); Height: 17” (432 mm)
  • Wet weight: 79 lbs (36 Kg)

PERFORMANCE

MAX FLOW: 65 GPM

MAX PRESSURE : 130 PSI

60 GPM @ 10 PSI

55 GPM @ 50 PSI

40 GPM @ 100 PSI

25 GPM @ 125 PSI

LIMITED WARRANTY

  • 3 YEARS
