PFP-14HPKHL-EM-MR

PRESSURE AND VOLUME PUMP

This pressure/volume pump is the most suitable for drop-in units. The engine and pump are mounted on a steel protective frame with folding handles

Also available in skid version

ENGINE SPECIFICATIONS

  • CH440 Kohler air cooled engine
  • Single cylinder, 4-stroke gasoline engine
  • 12V electric start with recoil start as backup
  • 1.8 gallon (7 l) integrated fuel tank
  • 10 amp. charging system

INCLUDED ACCESSORIES

  • Pressure gauge
  • 12V-Battery
  • Low oil shut-off

PUMP UNIT SPECIFICATIONS

  • C.E.T. single stage centrifugal pump, direct drive
  • Pump body made from high resistance aluminum alloy
  • Bronze impeller
  • Mechanical shaft seal
  • Exhaust priming system, guaranteed up to 20’ (6 meter) lift
  • One 1 1/2'' (38 mm) delivery outlet with 1/4-turn ball valve
  • One 2 1/2'' (64 mm) suction inlet
  • Dimensions: Length: 21 3/4'' (552 mm); Width: 26 1/2'' (673 mm); Height: 20 1/4'' (514 mm)
  • Wet weight: 162 lbs (74 kg)

PERFORMANCE

MAX FLOW: 240 GPM

MAX PRESSURE: 130 PSI

215 GPM @ 25 PSI

170 GPM @ 50 PSI

105 GPM @ 100 PSI

LIMITED WARRANTY

  • 3 YEARS
